HEIGHT: 108 in (274 cm)

WIDTH: 100 in (254 cm)

LENGTH: 176 in (447 cm)

WEIGHT: 7000 lbs (3176 kg)

DISCHARGE HEIGHT: 14 ft minimum (4.26 m)

LINE SIZE: 5 in (125 mm) & 6 in (150 mm)

AXLES: Two - 7000 lbs (3176 kg) ea

TIRES: Four - Highway tread

RIMS: 8 Bolt 16x9

BRAKES: Electric

FRAME: 2" x 6" (50 cm x 150 cm) tubular

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1618 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

ENGINE: John Deere, Model 6068T with 170 hp (127 kW) or equivalent

DRIVE: Twin Disk Clutch connected to belts

HYDRAULICS: Heavy duty gear type pump, filter, hoses, controls, etc.

RECEIVER 28 in diameter(71 cm) 2 piece. Dual inlets

PRECLEANER: 24 in diameter(61 cm)

SAFEGUARDS: Pressure and vacuum overload protection valves. Appropriate operation and warning decals. Appropriate belt guards.

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 108 in (274 cm)

WIDTH: 100 in (254 cm)

LENGTH: 176 in (447 cm)

WEIGHT: 7200 lbs (3265 kg)

DISCHARGE HEIGHT: 14 ft minimum (4.26 m)

LINE SIZE: 6 in (150 mm) & 7 in (175 mm)

AXLES: Two - 7000 lbs (3175 kg) ea

TIRES: Four - Highway tread

RIMS: 6 Bolt 15x6

BRAKES: Electric

FRAME: 2" x 6" (50 cm x 150 cm) tubular

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1618 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

ENGINE: John Deere, Model 6068T with 185 hp (138 kW) or equivalent

DRIVE: Twin Disk Clutch connected to belts

HYDRAULICS: Heavy duty gear type pump, filter, hoses, controls, etc.

RECEIVER 32 in diameter(81 cm) 2 piece. Dual inlets

PRECLEANER: 24 in diameter(61 cm)

SAFEGUARDS: Pressure and vacuum overload protection valves. Appropriate operation and warning decals. Appropriate belt guards.

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 108 in (274 cm)

WIDTH: 100 in (254 cm)

LENGTH: 176 in (447 cm)

WEIGHT: 7200 lbs (3265 kg)

DISCHARGE HEIGHT: 14 ft minimum (4.26 m)

LINE SIZE: 6 in (150 mm) & 7 in (175 mm)

AXLES: Two - 7000 lbs (3175 kg) ea

TIRES: Four - Highway tread

RIMS: 6 Bolt 15x6

BRAKES: Electric

FRAME: 2" x 6" (50 cm x 150 cm) tubular

BLOWER: #614 Walinga Super Chrome, positive displacement blower (X2)

AIRLOCK: #1618 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

ENGINE: John Deere, Model 6068T with 200 hp (149 kW) or equivalent

DRIVE: Twin Disk Clutch connected to belts

HYDRAULICS: Heavy duty gear type pump, filter, hoses, controls, etc.

RECEIVER 32 in diameter(81 cm) 2 piece. Dual inlets

PRECLEANER: 24 in diameter(61 cm)

SAFEGUARDS: Pressure and vacuum overload protection valves. Appropriate operation and warning decals. Appropriate belt guards.

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 139 in (353 cm)

WIDTH: 101-5/16 in (257 cm)

LENGTH: 297 in (754 cm)

WEIGHT: 12500 lbs (5670 kg)

DISCHARGE HEIGHT: 15 ft maximum (4.57 m)

LINE SIZE: 7 in (178 mm) & 8 in (203 mm)

AXLES: Two - 7000 lbs (3176 kg) ea

TIRES: Four - Radial Size Tires

RIMS: 8 Bolt 16x9

BRAKES: 4 Wheel Electric

FRAME: 2" x 6" (50 cm x 150 cm) tubular

BLOWER: 2 Chrome Hardened 614 Blowers

AIRLOCK: 2224 Cast Iron Drop Thru

ENGINE: 250 hp (186 kW) John Deere Diesel Engine

DRIVE: Two Disk clutch to belts

HYDRAULICS: Heavy duty gear type pump, filter, hoses, controls, etc.

RECEIVER 37-1/4" dia. (95 cm)

PRECLEANER: 31-3/16" dia. (79 cm)

SAFEGUARDS: Pressure and vacuum overload protection valves. Appropriate operation and warning decals. Appropriate belt guards.

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

WEIGHT: 770 lbs (350 kg)

HEIGHT: 60 inch (152 cm)

WIDTH: 36 inch (91 cm)

LENGTH: 78 inch (198 cm)

WHEELS: 3 pneumatic (1 on swivel)

BLOWER: #510 Walinga blower

AIRLOCK: #1210U two piece cast

FRAME: 1 piece formed steel

MOTOR/POWER: 10,15 or 20 hp (7.5,11,15 KW)

STARTER: "across the line"

RECEIVER: 18" dia. x 36" high (46 x 91 cm)

INLET: 4" (100 mm) daffin coupling with plug

OUTLET: 4" (100 mm) daffin coupling with plug

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

WEIGHT: 820 lbs (373 kg)

HEIGHT: 60 inch (152 cm)

WIDTH: 36 inch (91 cm)

LENGTH: 78 inch (198 cm)

WHEELS: 3 pneumatic (1 on swivel)

BLOWER: #510 Walinga blower

AIRLOCK: #1210U two piece cast

FRAME: 1 piece formed steel

MOTOR/POWER: 30 hp gas (22.3 KW)

STARTER: 12 Volt

RECEIVER: 18" dia. x 36" high (46 x 91 cm)

INLET: 4" (100 mm) daffin coupling with plug

OUTLET: 4" (100 mm) daffin coupling with plug

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

WEIGHT: 900 lbs (410 kg)

HEIGHT: 60 inch (152 cm)

WIDTH: 47 inch (119 cm))

LENGTH: 78 inch (198 cm)

WHEELS: mounted on legs

BLOWER: #510 Walinga blower

AIRLOCK: #1210U two piece cast

FRAME: 1 piece formed steel

MOTOR/POWER: 540 PTO (25 + hp)

STARTER: not applicable

RECEIVER: 18" dia. x 36" high (46 x 91 cm)

INLET: 4" (100 mm) daffin coupling with plug

OUTLET: 4" (100 mm) daffin coupling with plug

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 92 in (234 cm)

WIDTH: 92 in (234 cm)

LENGTH: 103 in (261 cm)

WEIGHT: 2352 lbs (1069 kg)

DISCHARGE HEIGHT: 13 ft 8 in minimum (4.49 m)

HP REQUIRED: 70-85 HP

PTO SPEED: 1000 RPM

LINE SIZE: 5 in (125 mm)

TIRES: Two standard farm implement

WHEELS: 15 in (38 cm), 5 stud

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1314 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

DRIVE: Torque mounted drive shaft with V-type 5 groove sheaves & belts

HYDRAULICS: Hoses & quick couplings Open/closed centre system

RECEIVER: 24 in diameter(61 cm) one piece, single inlet

PRECLEANER: 20" dia. (51 cm)

SAFETY: Vacuum/Pressure relief valves

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 92 in (234 cm)

WIDTH: 92 in (234 cm)

LENGTH: 103 in (261 cm)

WEIGHT: 2552 lbs (1160 kg)

DISCHARGE HEIGHT: 13 ft 8 in minimum (4.49 m)

HP REQUIRED: 70-85 HP

PTO SPEED: 1000 RPM

LINE SIZE: 5 in (125 mm)

TIRES: Two standard farm implement

WHEELS: 15 in (38 cm), 5 stud

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1314 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

DRIVE: Torque mounted drive shaft with V-type 5 groove sheaves & belts

HYDRAULICS: Self Contained

RECEIVER: 24 in diameter(61 cm) one piece, dual inlets

PRECLEANER: 20" dia. (51 cm)

SAFETY: Vacuum/Pressure relief valves

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 95 in (241 cm)

WIDTH: 92 in (234 cm)

LENGTH: 105 in (267 cm)

WEIGHT: 2814 lbs (1279 kg)

DISCHARGE HEIGHT: 13 ft 8 in minimum (4.49 m)

HP REQUIRED: 110-130 HP

PTO SPEED: 1000 RPM

LINE SIZE: 5 in (125 mm) & 6 in (150 mm)

TIRES: Two standard farm implement

WHEELS: 15 in (38 cm), 5 stud

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1618 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

DRIVE: Torque mounted drive shaft with V-type 5 groove sheaves & belts

HYDRAULICS: Hoses & quick couplings Open/closed centre system

RECEIVER: 28 in diameter(71 cm) one piece, single inlet

PRECLEANER: 24" dia. (61 cm)

SAFETY: Vacuum/Pressure relief valves

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 95 in (241 cm)

WIDTH: 92 in (234 cm)

LENGTH: 105 in (267 cm)

WEIGHT: 3014 lbs (1370 kg)

DISCHARGE HEIGHT: 13 ft 8 in minimum (4.49 m)

HP REQUIRED: 110-130 HP

PTO SPEED: 1000 RPM

LINE SIZE: 5 in (125 mm) & 6 in (150 mm)

TIRES: Two standard farm implement

WHEELS: 15 in (38 cm), 5 stud

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1618 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

DRIVE: Torque mounted drive shaft with V-type 5 groove sheaves & belts

HYDRAULICS: Self Contained

RECEIVER: 28 in diameter(71 cm) one piece, single inlet

PRECLEANER: 24" dia. (61 cm)

SAFETY: Vacuum/Pressure relief valves

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 96 in (244 cm)

WIDTH: 92 in (234 cm)

LENGTH: 107 in (272 cm)

WEIGHT: 2902 lbs (1319 kg)

DISCHARGE HEIGHT: 13 ft 8 in minimum (4.16 m)

HP REQUIRED: 130 - 150 HP

PTO SPEED: 1000 RPM

LINE SIZE: 6 in (152 mm) & 7 in (175 mm)

TIRES: Two standard farm implement

WHEELS: 15 in (38 cm), 5 stud

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #2018 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

DRIVE: Torque mounted drive shaft with V-type 5 groove sheaves & belts

HYDRAULICS: Hoses & quick couplings Open/closed centre system

RECEIVER: 32 in diameter(81 cm) one piece, single inlet

PRECLEANER: 24" dia. (61 cm)

SAFETY: Vacuum/Pressure relief valves

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.

HEIGHT: 92 in (234 cm)

WIDTH: 92 in (234 cm)

LENGTH: 103 in (261 cm)

WEIGHT: 3102 lbs (1410 kg)

DISCHARGE HEIGHT: 13 ft 8 in minimum (4.49 m)

HP REQUIRED: 70-85 HP

PTO SPEED: 1000 RPM

LINE SIZE: 5 in (125 mm)

TIRES: Two standard farm implement

WHEELS: 15 in (38 cm), 5 stud

BLOWER: #614 Walinga Super Chrome, positive displacement blower

AIRLOCK: #1314 cast iron shell, precision machined housing, 10 vane rotor with stainless steel tips, hydraulically driven, reversable rotation

DRIVE: Torque mounted drive shaft with V-type 5 groove sheaves & belts

HYDRAULICS: Self Contained

RECEIVER: 24 in diameter(61 cm) one piece, dual inlets

PRECLEANER: 20" dia. (51 cm)

SAFETY: Vacuum/Pressure relief valves

Due to continuous product development, specifications are subject to change without notice. Some items shown may be optional.

* Capacities based on using 12' (3.65 m) suction line and truck loading kit. Capacity will vary with condition of product.
